Prekės aprašymas
TELTONIKA industrial 5G gateway LTE TRB500
Specifikacijos
Tiekėjo prekės aprašymas
- 5G industrial gateway
- Aluminum body
- Mobile speed up to 1Gbps
- One of the smallest 5G gateways available in the market
- Backward compatible with 4G (LTE CAT 20) and 3G network technologies
- Mobile
- Mobile module5G Sub-6Ghz SA/NSA 2.1/3.3Gbps DL (4x4 MIMO), 900/600 Mbps UL (2x2); 4G (LTE) – LTE Cat 20 2.0Gbps DL, 200Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL
- StatusSignal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP Bytes sent/received, connected band, IMSI, ICCID.
- SMS/CallSMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, Call utilities
- USSDSupports sending and reading Unstructured Supplementary Service Data messages
- Black/White listOperator black/white list
- Band managementBand lock, Used band status display
- APNAuto APN
- BridgeDirect connection (bridge) between mobile ISP and device on LAN
- PassthroughGateway assigns its mobile WAN IP address to another device on LAN
- Ethernet
- LAN1 x RJ45 port, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
- Network
- Network protocolsTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL)
- RoutingStatic routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP)
- Connection monitoringPing Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
- FirewallPort forwards, traffic rules, custom rules
- DHCPStatic and dynamic IP allocation
- DDNSSupported >25 service providers, others can be configured manually
- SSHFSPossibility to mount remote file system via SSH protocol
- Security
- AuthenticationPre-shared key, digital certificates, X.509 certificates
- FirewallPre-configured firewall rules can be enabled via the WebUI, unlimited firewall configuration via CLI; NAT; NAT-T
- Attack preventionDDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
- VLANPort and tag-based VLAN separation
- Mobile quota controlSet up custom data limits for SIM card
- WEB filterBlacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
- Access controlFlexible access control of TCP, UDP, ICMP packets, MAC address filter
- VPN
- OpenVPNMultiple clients and a server can run simultaneously, 12 encryption methods
- OpenVPN EncryptionDES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
- GREGRE tunnel
- IPsecIKEv1, IKEv2, supports up to 5 x VPN IPsec tunnels (instances), with 5 encryption methods (DES, 3DES, AES128, AES192, AES256)
- PPTP, L2TPClient/Server services can run simultaneously, L2TPv3 support
- SSTPSSTP client instance support
- STUNNELProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s code
- DMVPNMethod of building scalable IPsec VPNs
- WireGuardWireGuard VPN client and server support
- ZeroTierZeroTier VPN
- MODBUS
- Modbus TCP Slave
- ID filteringRespond to one ID in range [1;255] or any
- Allow remote accessAllow access through WAN
- Custom registersMODBUS TCP custom register block, which allows to read/write to a file inside the router, and can be used to extend MODBUS TCP slave functionality
- Modbus TCP master
- Supported functions01, 02, 03, 04, 05, 06, 15, 16
- Supported data formats8 bit: INT, UINT; 16 bit: INT, UINT (MSB or LSB first); 32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII
- MQTT gateway
- GatewayAllows sending commands and receiving data from MODBUS Master through the MQTT broker
- DNP3
- Supported modesTCP Master, DNP3 Outstation
- Date to server
- ProtocolHTTP(S), MQTT, Azure MQTT, Kinesis
- Monitoring and management
- WEB UIHTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, system log, kernel log
- FOTAFirmware update from sever, automatic notification
- SSHSSH (v1, v2)
- SMSSMS status, SMS configuration, send/read SMS via HTTP POST/GET
- CallReboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer
- TR-069OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
- MQTTMQTT Broker, MQTT publisher
- SNMPSNMP (v1, v2, v3), SNMP trap
- JSON-RPCManagement API over HTTP/HTTPS
- MODBUSMODBUS TCP status/control
- RMSTeltonika Remote Management System (RMS)
- IoT PLATFORMS
- Cloud of ThingsAllows monitoring of: Device data, Mobile data, Network info, Availability
- ThingWorxAllows monitoring of: WAN Type, WAN IP Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
- CumulocityAllows monitoring of: Device Model, Revision and Serial Number, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength, WAN Type and IP
- Azure IoT HubCan send device IP, Number of bytes send/received/ 3G connection state, Network link state, IMEI, ICCID, Model, Manufacturer, Serial, Revision, IMSI, Sim State, PIN state, GSM signal, WCDMA RSCP WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ, CELL ID, Operator, Operator number, Connection type, Temperature, PIN count to Azure IoT Hub server
- System Characteristics
- CPUSingle core ARM Cortex A7, 1.5 GHz
- RAM256 MB (128 MB available for userspace)
- FLASH storage512 MB (200 MB available for userspace)
- Firmware / Configuration
- WEB UIUpdate FW from file, check FW on server, configuration profiles, configuration backup
- FOTAUpdate FW
- RMSUpdate FW/configuration for multiple devices
- Keep settingsUpdate FW without losing current configuration
- Firmware customization
- Operating systemRutOS (OpenWrt based Linux OS)
- Supported languagesBusybox shell, Lua, C, C++
- Development toolsSDK package with build environment provided
- Input/Output
- Configurable I/O2 x Configurable Inputs/Outputs. Digital input 0 - 5 V detected as logic low, 8 - 40 V detected as logic high. Open collector output, max output 30 V, 300 mA
- Output controlHTTP POST/GET, Schedule
- EventsSMS, EMAIL
- I/O jugglerAllows setting certain I/O conditions to initiate event
- Power
- Connector4-pin industrial DC power socket
- Input voltage range9 – 30 VDC, reverse polarity protection, surge protection >33 VDC 10us max
- Power consumptionIdle: <3 W, Max <6 W
- Physical Interferences(PORTS, LEDS, ANNTENAS, BUTTONS, SIM)
- Ethernet1 x RJ45 port, 10/100/1000 Mbps
- I/Os2 x Configurable I/O pins on 4-pin power connector
- USB1 x Virtual network interface via micro USB
- Status LEDs3 x connection type status LEDs, 3 x connection strength LEDs, 2 x LAN status LEDs, 1 x Power LED
- SIM1 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V
- Power1 x 4-pin DC power connector
- Anntena4 x SMA for Mobile
- ResetReboot/User default reset/Factory reset button
- GroundingGrounding screw terminal
- Physical SpecificationS
- Casing materialAluminum housing
- Dimensions (W x H x D)100 x 30 x 93,4 mm
- Weight241g
- Mounting optionsDIN rail, Flat surface
- Operating Environment
- Operating temperature-40 °C to 75 °C
- Operating humidity10 % to 90 % non-condensing
- Ingress Protection RatingIP30
Tiekėjo specifikacijos
Product code
LTETRB500
Category
Netw
Brand
Teltonika
Supplier's product code
LTETRB500
Product ID
U-2890435
Tiekėjo pateikiama informacija apie prekę gali skirtis nuo realaus produkto. Jei pastebėjote neatitikimų praneškite apie tai el. paštu [email protected].
